X-Axis Travel
27.95"
Y-Axis Travel
24.02"
Z-Axis Travel
25.98"
Pallet Size
19.68" x 19.68"
Max Weight of Workpiece
1,100 lbs
Table Indexing
FULL 4TH AXIS
Spindle Center To Table Top
1.96" -25.98"
Spindle Nose To Table Center
5.91" - 31.89"
Spindle Motor
30 HP
Spindle Taper
CAT 40
Spindle Speeds
12,000 RPM
Rapid Traverse Rate X,Y,Z
1,968 IPM
ATC
40
Max Tool Length
14.17"
Max Tool Diameter
5.740"
Max Tool Weight
26 lbs
Machine Weight
27,400 lbs
Mazatrol PC-Fusion 640M Control
Full 4TH AXIS TABLE
Coolant Thru Spindle
(2) Pallet Changer
Chip Conveyor
