NAKAMURA TW-20mm Twin Turret / Twin Spindle Multi-Axis CNC LATHE

Maximum Turning Diameter:

10.6"

Distance Between Centers:

42.5"

Main Spindle Nose:

A2-6

Main Spindle Speed:

5500 RPM

Main Spindle Bar Capacity:

2"

Main Spindle Chuck:

8"

Main Spindle Indexing:

.001°

Main Spindle Power:

20 HP / 24 HP

Sub Spindle Speed:

4500 RPM

Sub Spindle Bar Capacity:

2.56"

Sub Spindle Indexing:

.001°

Sub Spindle Power:

20 HP

Turret #1 Stations:

12

Turret #1 Driven Stations:

12

Turret #1 Driven Tool Speed:

3600 RPM

Turret #1 Driven Tool Power:

5 HP

Turret #1 X-Axis:

7.68"

Turret #1 Z-Axis:

30.71"

Turret #2 Stations:

12

Turret #2 Driven Stations:

12

Turret #2 Driven Tool Speed:

3600 RPM

Turret #2 Driven Tool Power:

5 HP

Turret #2 X-Axis:

7.68"

Turret #2 Z-Axis:

10.43"
