MAZAK QTN-350M CNC Multi-axis Turning Center
Have one to sell?
ConditionUsed
1 available
Maximum Swing:
29.5"
Swing Over Carriage:
20.87"
Maximum Cutting Diameter:
16.5"
Maximum Cutting Length:
80.6"
Spindle Nose:
A2-11
Hole Thru Spindle:
4.4"
Spindle Speed:
3300 RPM
Rotary Tool Spindle Speed:
4000 RPM
Rotary Tool Horse Power:
10 HP
Turret Confirguation:
12-Position
Turret Clamping Force:
11,700 Lbs
Stroke:
-- X-Axis:
10.2"
-- Y-Axis:
83.25"
-- Z-Axis:
.0001 ° increments
Rapid Traverse Rates:
-- X-Axis:
1181 IPM
-- Y-Axis:
1299 IPM
-- Z-Axis:
555 RPM
Tailstock Quill Diameter:
3.94"
Tailstock Center:
MT#5
Main Motor:
40 HP / 30 HP
Machine Weight:
22,417 Lbs
Mazatrol Matrix Nexus CNC Control
Steady Rest Base and Arm
12” Hydraulic Chuck
Tool Eye
Chip Conveyor
