Mazak QTN-250MSII Multi-Axis CNC Turning Center 2007

Maximum Swing.............................26.58"

Standard Machining Diameter...............10.87"

Maximum Machining Diameter................14.75"

Maximum Turning Distance..................21.27"

Spindle Motor .......................35 HP

Standard Bar Capacity ..................3"

Spindle Speed .........................4,000 RPM

Spindle Nose..............................A2-8

Second Spindle Chuck Size.............. ..6"

Second Spindle Nose.......................A2-5

Second Spindle Bore.......................2.07"

Second Spindle Maximum RPM................6,000

Second Spindle Power......................15 HP

Second Spindle Torque.....................58 ft/lbs (20 Min)

Second Spindle Full C-Axis control with 0.0001 Degrees Index

Turret Type...............................Modified VDI

Number of Tools...........................12

Tool Shank Size...........................3/4"

Mill Spindle Power........................7.5 HP (10 min)

Mill Spindle Maximum RPM..............4500 RPM

Turret Index Time..........................0.2 / 0.6 SEC

X-Axis Travel..............................9.0

Z-Axis Travel..............................22.63"

Rapid Traverse Rates X-Axis................1181 IPM

Rapid Traverse Rates Z-Axis................1299 IPM

Rapid Traverse Rates Second Spindle........1181 IMP

Machine Height.............................72.44"

Floor Space Requirement....................115.4" x 70.1"

Weight.....................................11,464 LBS
