Mazak Nexus QTN400M-II (3-axis) CNC Turning Center 2001

Maximum Swing:

33.268"

Maximum Turning Diameter:

22.835"

Maximum Turning Length:

41.672"

Maximum Bar Capacity:

4.587"

X-Axis Travel:

13.375"

Z-Axis Travel:

40.125"

C Axis Rotation:

360,000 Degree

Spindle Nose / Spindle Bore:

A2-11" / 5.2"

Spindle Speed:

2,500 RPM - 1 Range

Spindle Motor 30 minutes / Continuous:

50 HP / 40 HP

Live Tool Motor / Live Tool Speeds:

10 HP / 4,000 RPM

Turret Type - Modified VDI Type:

12 Position Turret-All Live

Rapid Traverse Rates X,Z / C:

1181 IPM / 555 RPM

Tailstock Body Travel / Center:

40.375" / MT #5

Machine Dimensions LxWxH:

156" x 90" x 80"

Machine Weight:

20,283 lbs.
